Generate file

The Generate file action constructs a CSV, text, or PDF file on the fly and lets the user download it.

Configuration

Parameter	Description	Default
Type	Type of file to be generated. Types: CSV, Text and PDF	—
File name	Name of the file to be generated	—
Data	Data that will be used to construct the file. Its format will depend on the file type, as specified in the following section	—
Debounce	Time in milliseconds to wait before executing the action	Empty (no delay)

CSV Data Format

To use the CSV file format, the data field should contain an array of objects. ToolJet assumes that the keys in each object are the same and represent the column headers of the CSV file.

Example:

{
  {
    [
      { name: "John", email: "[email protected]" },
      { name: "Sarah", email: "[email protected]" },
    ];
  }
}

Using the above code snippet will generate a CSV file with the following content:

name,email
John,[email protected]
Sarah,[email protected]

Text Data Format

To use the Text file format, the data field should contain a string.

If you want to generate a text file based on an array of objects, you need to stringify the data before providing it.

For example, if you are using the table component to provide the data, you can enter {{JSON.stringify(components.table1.currentPageData)}} in the Data field.

PDF data format

The PDF data format supports two types of input: either a string or an array of objects. When using an array of objects, the resulting PDF will display the data in a tabular format with columns and rows. On the other hand, if a string is provided, the generated PDF will consist of plain text.

Triggering via RunJS

actions.generateFile('<fileName>', '<fileType>', '<data>');

fileName is the name to give the file (string), fileType is one of csv, plaintext, or pdf, and data is the data to store in the file.

// CSV
actions.generateFile('csvfile1', 'csv', '{{components.table1.currentPageData}}');

// Text
actions.generateFile('textfile1', 'plaintext', '{{JSON.stringify(components.table1.currentPageData)}}');

// PDF
actions.generateFile('pdffile1', 'pdf', '{{components.table1.currentPageData}}');

info

For a full quick-reference of all actions' RunJS syntax, see Run Actions from RunJS.
